Description
Specifications:
|
Model |
S5331D |
|
Solder Joint Range |
X500* Y1/300*Y2/300*Z100mm（XxYxYxZ） |
|
Solder Time |
1.0~1.5s/point |
|
Repeat Positioning Accuracy |
±0.002mm |
|
Solder Wire Diameter |
0.5, 0.6, 0.8, 1.0, 1.2 (mm) |
|
Air source |
0.4-0.6 MPA |
|
Axis |
4 |
|
Program Capacity |
999 files, each file can save up to 999 points |
|
External Dimensions (W x D x H) |
820mm x 600mm x 800mm |
|
Weight |
about 65kgs |
Features:
1.High power heating controller ensures the tip temperature to reach 350°C within 30 seconds;
2.With the sleeve design, the soldering tip can be replaced quickly and easily.
3.Intelligent solder feeding mode, parameters can be set freely.
4.Automatic tip cleaning function by airflow cleaning, the residual dross on the tip can be blown off easily.
